Omron NJ501-1300 (NJ501-1300)

Marka : Omron

FİYAT VE TESLİM SÜRESİ İÇİN LÜTFEN İLETİŞİME GEÇİNİZ!







Sysmac NJ5 CPU, 20 mB memory, built-in EtherCAT (16 servo axes, in total 192 EtherCAT nodes) and EtherNet/IP

Controller functionality Motion control, OPC-UA, Sequence control
Max. number of synchronous axes 16
Max. number of axes (incl. virtual) 16
Max. number of robots 0
Primary task cycle time 0.5 ms
Program memory 20 MB
Variables memory 6 MB
Communication port(s) EtherCAT Master, EtherNet/IP, USB
Communication option(s) CAN, CompoNet Master, DeviceNet Master, DeviceNet Slave, EtherCAT Slave, MODBUS Master, MODBUS Slave, PROFIBUS DP Master, PROFIBUS DP Slave, PROFINET Master, Serial RS-232C, Serial RS-422, Serial RS-485
Max. number of remote I/O nodes 192
I/O system CJ I/O Bus
Max. number of expansion units 40
Height 90 mm
Width 90 mm
Depth 90 mm
Weight 550 g
