Omron NX-ID5142-1
Omron NX-ID5142-1

Omron NX-ID5142-1 (NX-ID5142-1)

Marka : Omron

FİYAT VE TESLİM SÜRESİ İÇİN LÜTFEN İLETİŞİME GEÇİNİZ!









16 Digital Inputs, Standard speed, NPN/PNP 24 VDC, screw connector, 30 mm wide

I/O system NX I/O Bus
Type of module Digital I/O
Number of digital inputs 16
Digital input type PNP/NPN
Permitted voltage at input 15-28.8 V
OFF/ON delay 0.02-0.4 ms
Number of digital outputs 0
Digital output type None
Short-circuit protected outputs x
Connection method 1-wire
Signal processing Free running, Standard speed, Synchronous
IO link master x
I/O connection type Screw
Number of I/O connectors 1
Detachable I/O connector
Suitable for safety functions x
SIL according to IEC 61508 None
Communication port(s) None
Number of IOV (V+) terminals 0
Number of IOG (V-) terminals 0
Number of COM terminals 2
Degree of protection (IP) IP20
Height 100 mm
Width 30 mm
Depth 95 mm
Weight 125 g
